Anilam 6000M - Page 75

CNC Setup Utility Manual
P/N 70000490C - Machine Constants
All rights reserved. Subject to change without notice.
10-December-04
2-65
Table 2-2, Machine Constants Setup (Continued)
Machine Constant
Parameter
Function Settings
Tool Management Setup Parameters
MC_5000:
Activate tool length
offset
See “Activation Options
.” No - Function is not used.
On Tn - Function activates only
when a tool is activated (T-Word).
On M6 - Function activates only
when Tool Changer M-function
(M6) activated.
Both [Default] - Function activates
when a tool number or M6 is
activated.
MC_5001:
Output signal
See “Activation Options
.”
No [Default]
On Tn
On M6
Both
MC_5002:
Orient spindle
See “Activation Options
.”
No [Default]
On Tn
On M6
Both
MC_5003:
Default spindle
orientation angle
Selects an angle of orientation beyond
the marker pulse. The range is 0.1 to
360 degrees. This feature eliminates
the need for exact mechanical
positioning of the spindle encoder. The
spindle orientation angle is
programmable via CNC software. Enter
angle value in degrees.
Range (0.0–360 degrees)
0.0 [Default]
MC_5004:
Spindle orientation
RPM
Specifies the orientation RPM of the
spindle. Consult relevant spindle drive
documentation for proper spindle speed
encoding and appropriate orientation
speeds. Maximum programmable
orientation spindle speed is 50 RPM.
Refer to “Enabling M19 Commands
.”
Enter orientation RPM.
Range (1–250)
10 (rev/min) [Default]
MC_5006:
Stop program
execution
Halts the running program until given a
Cycle Start from the Manual Panel. For
manual tool change operations using a
Programmable Controller, set this
selection to No (disabled). For manual
tool change operations without a
Programmable Controller, set to On Tn.
The CNC will hold program run and
display a message. Press
START to
resume program run.
No [Default]
On Tn
On M6
Both
(Continued…)
