Anilam 6000M - Page 76

CNC Setup Utility Manual
P/N 70000490C - Machine Constants
2-66 All rights reserved. Subject to change without notice.
10-December-04
Table 2-2, Machine Constants Setup (Continued)
Machine Constant
Parameter
Function Settings
MC_5007:
Tool changer installed
Refer to “Enabling M19 Commands
.” None – Disables M19
Fixed Rep. [Default] – Fixed
Replacement; active tool always
returned to the same bin after use.
Random Rep. – Random
Replacement; active tool can be
placed in the next available bin.
CNC indexes the tool changer and
keeps track of the bin number
corresponding to each tool number.
Adds Fix and Bin columns to the
Tool Page. BIN specifies BIN in
which a tool is initially located. FIX
specifies if the corresponding tool
needs to go back into the same BIN
from which it was taken.
MC_5008:
Use tool change
macro
See “Guidelines for Setting Tool
Change Macro Parameters.”
No [Default]
On Tn
On M6
Both
MC_5009:
Tool change macro
program
Filename of the macro to be used
during tool change operations. Enter
Macro filename. See “Guidelines for
Setting Tool Change Macro
Parameters.”
TC.G [Default]
MC_5010:
Tool change macro
number
Macro Number to be used during tool
change operations. Macro files can
contain more than one macro (number).
Enter Macro Number. See “Guidelines
for Setting Tool Change Macro
Parameters.”
Range (8000–9000)
O8000 [Default]
MC_5011:
Number of digits in T
word
A 4-digit word will allow selection of
from 1 to 99 tools. A 6-digit word will
allow selection of from 1 to 999 tools.
See “Guidelines for Setting the Number
of Digits for T-Words.”
Range (4 or 6)
4 [Default] T-word Format
MC_5012:
Number of bins in tool
changer
Enter number of bins. Range (0–99)
0 [Default]
MC_5013:
Number of Tools to
display in table
Limits the number of tools displayed in
the tool table. Enter maximum number
of tools.
Range (25–255)
99 [Default]
MC_5014:
Default tool-table file
Enter filename. P6MTOOL.DAT
