Table 2-2, Machine Constants Setup (Continued)
Machine Constant
Parameter
Function Settings
MC_5106:
Gauge 2 Active
Gauges allow you to monitor analog
inputs that vary from zero to 5 VDC (for
example, DC outputs for drive
controllers, adjustment potentiometers,
etc.).
No (deactivate) [Default]
Yes (activate )
MC_5107:
Gauge 2 Name
Assign a name (e.g., spindle load) to
the gauge in the entry field.
Blank [Default]
MC_5108:
Gauge 2 Type
Assign a value of 0 to the gauge in the
entry field. This allows monitoring of
the spindle load on the particular
gauge. Other types of monitoring will
be provided in the future.
Range (0–5)
0 [Default]
MC_5109:
Gauge 3 Active
Gauges allow you to monitor analog
inputs that vary from zero to 5 VDC (for
example, DC outputs for drive
controllers, adjustment potentiometers,
etc.).
No (deactivate) [Default]
Yes (activate)
MC_5110:
Gauge 3 Name
Assign a name (e.g., spindle load) to
the gauge in the entry field.
Blank [Default]
MC_5111:
Gauge 3 Type
Assign a value of 0 to the gauge in the
entry field. This allows monitoring of
the spindle load on the particular
gauge. Other types of monitoring will
be provided in the future.
Range (0–5)
0 [Default]
(Continued…)
