Animo OptiBean Touch - Specifications; Standard Machine; Electrical System

2017/06 Rev. 2.0 67 EN
OptiBean (XL) Touch
2.2.5 Outlet
The outlet (A) transfers the product into the cup or jug.
2.3 Specifications
2.3.1 Standard machine
/i
2.3.2 Electrical system
/i
2.3.3 Power consumption (according to EVA - EMP standard)
/i
A
Item Specification
Machine dimensions 402 x 564 x 790 mm
Weight: empty/full 36/40 kg
Pressure 2-10 bar
Water temperature 90 °C
Water hardness > 5 °dH
Water acidity 6,5 < pH <8,5
Boiler volume 1.1 l
Boiler heating time 3 min
Boiler temperature 90 °C
Acoustic pressure < 70 dB(A)
Item Specification
Voltage 1N~220-240V
Frequency 50-60 Hz
Power 2100 W
Heating element power 1900 W
Fuse 10 A
Item Specification
Reaching operating temperature (HU) 107 Wh
