Chapter 1 — General Information
1-1 Introduction
This chapter provides information about the VectorStar
®
Broadband/Banded Millimeter-Wave Modules. These
modules are used with the ME7838 Series VectorStar
®
Broadband/Banded Millimeter-Wave VNA Systems.
1-2 Broadband/Banded Millimeter-Wave Modules
Table 1-1. Millimeter-Wave Module Models
Model Description Frequency Band
MA25400A Broadband Millimeter-Wave Module 70 kHz to 220 (226) GHz
MA25300A Broadband Millimeter-Wave Module 70 kHz to 145 GHz
3743A Broadband Millimeter-Wave Module 70 kHz to 125 GHz
3743E Broadband Millimeter-Wave Module 70 kHz to 110 GHz
3744A-EE Banded Millimeter-Wave Module 56 GHz to 95 GHz
3744A-EW Banded Millimeter-Wave Module 65 GHz to 110 GHz
3744E-EE Banded Millimeter-Wave Module 56 GHz to 95 GHz
3744E-EW Banded Millimeter-Wave Module 65 GHz to 110 GHz
3744A-Rx Receiver Module 30 GHz to 125 GHz
3744E-Rx Receiver Module 30 GHz to 110 GHz
–
Waveguide Accessory Kit
a
, 3744A-EE and 3744A-EW
a. The Waveguide Accessory Kit comes without the adapter bracket, waveguide to coax adapter, and V210 termination. These
items come already attached to the 3744A-EE, 3744A-EW, 3744E-EE, and 3744E-EW mmW modules.
–
SM6540 WG Adapter Kit, V Band WR-15
35WR12WF-EE WG Adapter Kit, E Band WR-12
35WR10WF-EW WG Adapter Kit, W Band WR-10
