Preset Menu
5-8 PN: 10580-00277 Rev. E Spectrum Master UG
5-4 Preset Menu
Key Sequence: Shift, Preset (1)
5-5 Power On Self Test
At power on, the Spectrum Master runs through a series of quick checks to ensure that the
system is functioning properly. The System self test (refer to “Self Test” on page 5-3) runs a
series of tests that are related to the instrument. The Application Self Test (refer to
“Application Self Test” on page 5-3) runs a series of tests that are related to the current
operating mode of the instrument.
If the Spectrum Master is within the specified operating range with a charged battery, and if
the self test fails, then contact your Anritsu Service Center.
To initiate a self test when the system is already powered up:
1. Press the Shift key and then the System (8) key.
2. Press the
Self Test submenu key. The Self Test results are displayed.
Press the Esc key to continue.
Preset: This key resets the instrument to the default starting conditions.
Save Setup: Opens the Save dialog box to name and save the current
operating settings, allowing them to be recalled later to return the instrument
to the state it was in at the time the setup was saved.
Recall Setup: This key allows the selection and recall of a previously stored
instrument setup. All current instrument settings are replaced by the stored
setup information.
Figure 5-8. Preset Menu
Recall
Setup
Preset
Save
Setup
Preset
