12
Start of the fiber Splitter Event
Reflective Event
End of the fiber
Non-Reflective Event
Questionable Event
Grouped Event Patch cord (Launch)
Macro Bend Event
Patch cord (Receive)
For soft keys on right hand, refer to the description in Trace. Note that
only Swap Overlay appears for Overlay key in Fiber Visualizer.
Event distance
Event number
Distance from previous event
Event icon
Connection loss at event point
Fiber loss
Reflection at event point
"S" appears if the reflection
level is saturated.
Trace image of the event
To Next Page
