Page 32 of 39 Technical Documentation ECE10CM, DC10CM
R161 ♦ permanently excited DC motors with DC tachogenerator
R161
Tacho voltage
[VDC]
S1-1 = OFF
S1-2 = OFF
10 kΩ
11 - 20
22 kΩ
20 - 35
33 kΩ
25 - 45
47 kΩ
35 - 60
56 kΩ
40 - 70
68 kΩ
45 - 85
82 kΩ
55 - 100
S1-3 ON = Speed regulator cutout
with nominal and actual speed < 2% of maximum speed
(Setting is recommended for ECE block commutation)
OFF = no speed regulator cutout at low speeds.
S1-4 ON = Function "reference / actual value deviation“
OFF = Function "n < REF“
