ANTEK ECE10CM Series User Manual

Technical Documentation ECE10CM, DC10CM Page 39 of 39
10.3 Commutation Tables
Block Commutation
ECE10CM-00 ANTEK MAYR Papst WEG ATS
Terminal
Function
UE
51, 52
SDS
45, 56
X2-2
W
W W
X2-3
F
F F
X2-4
U
U U
X3-1
SC
G
w
L
r
X3-2
SB
G
v
L
s
X3-3
SA
G
u
L
t
X3-4
GND
GND minus -
X3-5
+15VDC
VCC plus +
Sinusoidal Commutation
ECE10CM-02 ANTEK ATS
Terminal
Function
EC
045, 056
SDS
045, 056
X2-4
U
U U
X2-3
F
F F
X2-2
W
W W
X3-1
SIN
C S2
X3-2
COS
E S1
X3-3
REF
A R1
X3-4
GND
B, D, F S4, S3, R2
