11. TECHNICAL DATA
Installation plan:
A5
A6 PLUS
97042163
A6 PLUS
97042164
Technical manual:
97071265
Spare parts catalogue:
97023177
Maximum dental unit weight:
90 kg
Maximum dental chair weight:
115 kg
Maximum dental chair capacity:
190 kg
Rated voltage:
220-240 V~
100-120 V~
Rated frequency:
50/60 Hz.
Rated current:
10 A (220-240 V~)
15 A (100-120 V~)
Air connection:
1/2 Gas.
Air supply pressure:
6-8 bar.
Air delivery flow rate:
82 l/min.
Water connection:
1/2 Gas.
Water supply pressure:
3-5 bar.
Water supply pressure:
10 l/min
Water consumption:
2 l/min.
Water hardness:
< 25 °f (14 °d)
Drain connection:
ø40 mm
Drainage flow rate:
10 l/min.
Drain duct inclination:
10 mm/m.
Suction connection:
ø40 mm.
Suction vacuum
(minimum):
65 mbar.
Suction flow rate:
450 l/min.
Mark of approval:
CE 0051
Electrical work in compliance
with:
IEC 60364-7-710
Dental unit packaging
dimensions:
A5
1540x750x1330(h)
A5
CART
1540x750x1330(h)
1540x750x1120(h)
A5
SINGLE
CART
1540x750x1120(h)
A6 PLUS
1540x750x1330(h)
L6
1540x750x1480(h)
Dental chair packaging
dimensions:
A2.5
A2.7
1480x700x1000(h)
A1.3 L
1480x700x1000(h)
Packed dental unit weight:
A5
140 kg
A5 CART
140 + 45 kg
A5 SINGLE
CART
45 kg
A6 PLUS
140 kg
L6
150 kg
Packed dental chair weight:
A2.5
A2.7
140 kg
A1.3 L
140 kg
Radio module technical
specifications:
Cloud module
Type of transmission: Wi-Fi
Operation frequency band: 2412 - 2484 MHz
Maximum power: +21.5 dBm
Wireless pedal module
Type of transmission: Bluetooth®
Operation frequency band: 2402 - 2480 MHz
Maximum power: +4 dBm
FUSES
Identification
Value
Protection
Position
MAIN
Fuse
T 10 A
T 15 A
220-240 V ~: Dental unit power supply line
100-120 V ~: Dental unit power supply line
Connection box
DENTAL CHAIR
Fuse F1
T 6.3 A
220-240 V ~: Dental chair power supply line.
Connection card
DENTAL CHAIR (INVERTER)
Fuse F1
Fuse F2
T 6.3 A
T 8 A
T 10 A
220-240 V ~: Inverter power supply line
100-120 V ~: Inverter power supply line
Inverter motor
Inverter card
Inverter card
QUICK COUPLINGS
Fuse
T 2 A
220-240 V ~: Power outlet supply line
Connection box
