- 19 -
Step 8 Device Operation
The CX7 terminal support access control functions as described
CX7 Access Control Wiring
Exit
Button
Door Sensor
Magnetic Lock
FR 107
+
-
+12 GND GNDNO NCPUSH
Access Control Power Supply
INPUT:AC110/230 V 50HZ
OUTPUT:DC12V, 3Amps+
COM
GND
D/M
485B
485A
GND
WI0
WI1
12VNC
NO
D/S
Bell+(5V)
WO0
WO1
DC12V Power Adapt
Wiegand Input Exit
Wiegand Output
GND Relay Output
WI0
WI1 D/S
Bell(5V)
Door
Sensor
GND
RS485
NULL
Power
Input
Relay
Output
Bell D/M 485B 485A 12V
Access Control I/O
Function
Function
To be reviewed after CX7 connection with the cloud software.
There are four status icon display on the right top of the screen:
Click then enter admin ID and
password to access the main
menu.
The status of the WIFI connection.
The status of the LAN connection.
The status of the Cloud connection.
The status of the Access Control.
8213
Clark Steve
IN
14:49:11
Jennifer
20 0 02 2 20 / /
AM
Main
Network
Update
Test
T&A
Access
(The defualt ID “0”, password “12345”)
