AOC C3583FQ User Manual

46
Specification
General Specification
Panel
Model name
C3583FQ
Driving system
TFT Color LCD
Viewable Image Size
890 mm diagonal
Pixel pitch
0.32025(H)mm x 0.32025(V)mm
Video
R, G, B Analog Interface& Digital Interface & HDMI lnterface&
DP Interface
Separate Sync.
H/V TTL
Display Color
16.7M Colors
Dot Clock
VGA:205MHz;
DP: 600MHz;
Dual link DVI/HDMI/MHL: 300MHz
Resolution
Horizontal scan range
30~99KHz ( MHL)
30~160KHz ( D-sub, DVI Dual link ,HDMI )
30~190KHz(DP)
Horizontal scan
Size(Maximum)
820mm
Vertical scan range
23~76Hz(MHL)
50~146Hz( D-sub, DVI Dual link ,HDMI )
45~162Hz (DP)
Vertical scan Size(Maximum)
346mm
Optimal preset resolution
MHL:1920×1080@60Hz
D-sub/DVI-D(Dual link)/HDMI:2560x1080@60Hz
DP:2560x1080@60Hz
Plug & Play
VESA DDC2B
Input Connector
R/G/B Analog, DVI-D(Dual link), HDMI/MHL, DP, Audio in
Input Video Signal
Analog: 0.7Vp-p(standard), 75 OHM, Positive TMDS
Output Connector
Earphone out
Power Source
20VDC, 4.5A
Power Consumption
Typical (Brightness = 90,Contrast = 50)
60W
Max. (Brightness = 100,Contrast =100)
≤95W
Power saving
≤0.5W
Off timer
0-24 hrs
Physical
Characteristics
Connector Type
R/G/B Analog, DVI-D(Dual link), HDMI/MHL, DP, Earphone
out, Line-In
Signal Cable Type
Detachable
Height (with base)
844.6 mm
Width
458 mm
Depth
213.6 mm
Weight (monitor only)
11.6kg
Environmental
Temperature:
Operating
0° to 40°C
Non-Operating
-25° to 55°C
Humidity:
Operating
10% to 85% (non-condensing)
Non-Operating
5% to 93% (non-condensing)

AOC C3583FQ Specifications

General

3D	No
HD type	QXGA
Panel type	MVA
Color depth	8 bit
Pixel pitch	0.32025 x 0.32025 mm
Aspect ratio	21:9
Backlight type	W-LED
Display surface	Matt
Display diagonal	35 \
Screen curvature	2000 mm
Display resolution	2560 x 1080 pixels
Display technology	LED
Vertical scan range	45 - 160 Hz
Horizontal scan range	30 - 170 kHz
Screen curvature rating	2000R
Viewable size, vertical	345.87 mm
Contrast ratio (dynamic)	50000000:1
Contrast ratio (typical)	2000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	819.84 mm
Display brightness (typical)	300 cd/m²
Supported graphics resolutions	2560 x 1080
HDCP	Yes
HDMI version	1.4
DisplayPort version	1.2
Headphone connectivity	3.5 mm
Certification	GOST
Product color	Black
Heavy metals free	Hg (mercury), Pb (lead)
Market positioning	-
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	95 W
Annual energy consumption	90 kWh
Power consumption (standby)	0.5 W
Power consumption (typical)	60 W
Tilt angle range	-3 - 15 °
Cable lock slot type	Kensington
Number of OSD languages	16
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, ESP, FIN, FRE, ITA, JPN, KOR, POL, POR, RUS, SWE
Mean time between failures (MTBF)	30000 h
RMS rated power	5 W
Package type	Box
Package depth	280 mm
Package width	980 mm
Package height	610 mm
Package weight	Weight of the packaged product in gram.
Cables included	AC, Audio (3.5mm), DisplayPort, HDMI, VGA
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-25 - 55 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 93 %
Operating relative humidity (H-H)	10 - 85 %
Sustainability certificates	RoHS, EPEAT Gold, ENERGY STAR

Weight and Dimensions

Depth (with stand)	213.6 mm
Width (with stand)	844.6 mm
Height (with stand)	458 mm
Weight (with stand)	11600 g
Depth (without stand)	- mm
Weight (without stand)	- g
