Thank you for choosing AOpen i865 Family motherboards. AOpen i865 Family Motherboard is Intel
®
Socket 478 motherboard (M/B)
based on the ATX form factor featuring the Intel 865G chipsets (for AX4SG series), Intel 865PE chipsets (for AX4SPE series) and Intel
848P chipsets (for AX4SPB series). As high performance chipset built in the M/B, AOpen i865 Family motherboard supports Intel
®
Socket 478 Pentium
®
4 1.6GHz~3.20GHz. It supports 400/533/800MHz Front Side Bus (FSB) clock and Hyper-Threading Technology
that brings additional intelligence to systems. In the AGP
performance, it has one AGP slot to support AGP 8X/4X mode and pipelined
spilt-transaction long burst transfer up to 2112MB/sec. For AX4SG series, it integrates VGA Engine in chipset and AGP 8X slot also
support ADD cards. According to different customer’s requirements, this M/B supports DDR266
, DDR333 and DDR400 RAM up to 4GB
maximum in Dual Channel mode. For AX4SPB series, it only has two RAM slots and supports Single Channel mode with maximum
capacity up to 2 GB. The onboard IDE controller supports Ultra DMA 33/66/100
mode and Serial ATA 150 MB/s. There are 5 PCI slots
provided on this board. A total of four USB 2.0
ports on the
back panel and two headers on the board give you the best
use of all USB devices with the fancy speed up to 480Mbps.
More than that, on the strength of integrated Realtek LAN
controller on board, which is a highly integrated Platform LAN
Connect device, it provides 10/100 Mbps Ethernet (for -UL
series, it is 10/100/1000 Mbps) for office and home use. For
–U series motherboards, they do not support LAN onboard.
Besides, AOpen i865 Family motherboard has S/PDIF
connector and an AC’97 CODEC Realtek
chipset onboard,
providing high performance and magic surround stereo
sound to let people enjoy working with it. Now, let’s enjoy all
features from AOpen i865 Family motherboards.

AOpen AX4SG-U Specifications

General

Brand	AOpen
Model	AX4SG-U
Category	Motherboard
Language	English
