Motherboard Map
JP28 Keyboard/Mouse
Wakeup Jumper
Colored Back Panel
JP14 CMOS Clear Jumper
Front Audio Connector
Front Panel Connector
SYSFAN2 Connector
ATA 66/100 IDE Connectors x2
FDD Connector
184-pin DIMMsx4 support Dual Channel
DDR400/333/266 Max. To 4 GB
(for AX4SG and AX4SPE series)
184-pin DIMMx2 support Single Channel
DDR400/333/266 Max. To 2GB
(for AX4SPB series)
ATX Power Connector
Intel 865G/865PE/848P Chipset that
supports 400/533/800MHz FSB,
DDR 266/333/400 and AGP 8X
478-pin CPU socket (Northwood)
with Voltage and Frequency
Auto-detection that supports Intel
®
Pentium
®
4 1.6~3.20GHz+ CPU
AGP Protection LED
Connector SYSFAN1
Low ESR Capacitors
4-pin 12V. ATX Power Connector
32-bit PCI Expansion Slots x5
USB 2.0 Connectors x 2
4Mb Flash ROM BIOS
Onboard AC’97 CODEC
AUX-IN Connector
S/PDIF Connector
CD-IN Connector
SATA Ports x 2
COM2 Connector
Game Port Connector
IrDA Connector
Case Open Connector
AGP 8X Expansion Slot
(for AX4SG series, it also supports
ADD card.)
Realtek Gigabit LAN chip
(for -UL series)
Realtek 10/100 Mbps LAN chip
(for -UN series)
CPUFAN Connector

AOpen AX4SG-U Specifications

General

Brand	AOpen
Model	AX4SG-U
Category	Motherboard
Language	English
