AWARD BIOS
3-30
Integrated Peripherals Onboard FDC Controller
Onboard FDC
Controller
Enabled
Disabled
Setting this parameter to Enabled allows you to
connect your floppy disk drives to the onboard floppy
disk connector instead of a separate controller card.
Change the setting to Disabled if you want to use a
separate controller card.
Integrated Peripherals Onboard Serial Port 1
Integrated Peripherals Onboard Serial Port 2
Onboard Serial Port
1
Auto
3F8/IRQ4
2F8/IRQ3
3E8/IRQ4
2E8/IRQ3
Disabled
This item allow you to assign address and interrupt for
the board serial port. Default is Auto.
Note: If you are using an network card, make
sure that the interrupt does not conflict.
Integrated Peripherals UART Mode Select
UART Mode Select
ASKIR
IrDA
This item selects the mode of onboard wireless
Infrared controller. The IrDA standard includes both
HPSIR and FIR, the driver in the Win95 will
automatically change to different mode according to
different chip.
• ASKIR - Select this setting if you installed an Infrared module via IrDA
connector (refer to section 2.3 "Connectors"). This ASKIR setting allows
infrared serial communication at a maximum baud rate of 56K baud.
• HPSIR - Select this setting if you installed an Infrared module in your
system via IrDA connector (refer to section 2.3 "Connectors"). The
HPSIR setting allows infrared serial communication at a maximum baud
rate of 115K baud.
