135
With EM8200 ‘not’ fitted: Use the key sequence to recall the loaded
band scope to LCD.
With EM8200 fitted: Use the key sequence to access the band scope
load menu, the legend “B-SCOPE LOAD” will be displayed.
the key to toggle the memory selection between INTERNAL “INT” and EXTERNAL
“EXT”, the default is “EXT”. As band scope data has been transferred to internal memory select “INT”.
to recall the trace to LCD.
Loading a band scope directly from external memory for viewing
Section 18-6-7
