PowerCables

ConnectCablesBetweentheUPSandthePDU-XR

SchneiderElectricrecommendsusinga45ºcablelug.Ifyouusestraightcable

lugs,installabusbarsafetybracketbetweeneachbusbarandcablelugto

ensureasafemeasureofseparation.ThebracketsareprovidedwiththeUPS.

SchneiderElectricrecommendsusingmultiexiblecoppercablestoroutethecablesasshown.

Caution:Ensureclockwisephaserotationandneutrallocation.Thepowerterminalbolt

diameteris10mmandtherequiredtorquevalueis26Nm.

Note:Donotremovethe12pcsM10nylonhexboltsfromthebusbars.Mountthecablesin

theopenholes.

Note:IntheUPS,routethecablesontheoutsideoftheguiderailswhenpossible(see

illustration).

Note:TheM10bolts,washersandcabletiesaresuppliedintheUPSaccessorykit.

990–3017E-001

SymmetraPX96and160kW400VInstallation
