ProcedureforSystemwithPDU-XR

1.Mechanicalassembly(notshownonthedrawing)

2.Connectthecommunicationcables

3.Connectthenetworkcommunicationcable

4.ConnecttheEPO

5.Connectthebatterycables

6.ConnectthepowercablesbetweentheUPSandthePDU-XR

7.Interconnectandlevelthecabinets

8.ConnecttheinputandoutputcablestothePDU-XR

Note:InputneutralisalwaysON.InputneutralisneverswitchedOFFwhenQ1circuit

breakerisswitchedONorOFF.Acontinuousgroundedneutralmustbeconnectedtothe

inputoftheUPS.ThisconnectionensuresthattheUPSNeutralremainsgroundedwhile

inbatteryoperationmode.OperationofUPSinbatterymodewithoutthecontinuously

groundedneutralcanresultinexcessivevoltagepotentialsbetweengroundandlinevoltage.

Thisexcessivevoltagepotentialcouldleadtodamagetoexternallyconnectedequipment.

TheneutralconnectiontotheloadisswitchedwhenoperatingQ2andQ3.

SymmetraPX96and160kW400VInstallation

990–3017E-001
