Sensor Number (SENNUM):
Sets the PG10’s sensor address number for the RS-485 Modbus
communications. Options: 1 Stop bit, 2 Stop bits
Setting the number of Stop Bits:
Step 1: Press to enter the main setup menu.
Step 2: Press or to cycle through the options until COMM is
displayed.
Step 3: Press to access the Communications settings menu.
Step 4: Press or to cycle through the options until SENNUM is
displayed.
Step 5: Press to access the Sensor Number setting. A 3-digit number will
appear with the rst digit ashing.
Step 6: Press or to change the value of the rst ashing digit.
Step 7: Press to accept the value of the ashing digit and advance to the
next digit......repeat steps 6 and 7 until the desired sensor address
number is entered. The PG10 will automatically return to the
Communications menu once the last digit is entered.
MODE
ENTR
ENTR
ENTR
