API The BOX - Cue Master Rear Panel Connections

API “The BOX” Operator’s Manual
62
8.2 Cue Master Rear Panel Connections
AUX OUTPUTS / CUE OUTPUTS: DB-25, balanced,
low-impedance, line-level
• Fed from the aux and cue masters
• Standard pin-out: 1-4=aux outputs 1-4,
5-6=cue outputs L-R
