API “The BOX” Operator’s Manual
37
3.3 Output Routing and Pan-Pot
Each summing input can be routed to the program bus via the PGM assignment
switch. The program bus is fed post-fader/mute and pan-pot.
Program Bus Assignment
Stereo Pan-Pot
PGM (Program): Assigns the summing channel output to the program
bus when engaged
• Program bus is fed post-pan-pot
• Illuminates when engaged
PAN (pan-pot): Continuously variable left-right stereo pan-pot
• Program bus is fed post-pan-pot
• -3dB pan law (-3dB per side when panned center)
• Center detent
