A1 12 DTR.APC.APR.ALW.03
(ENG)
Appendix MID
4. List of completeness.
Together with APC-2000ALW transmitters user receives:
a) Product Certificate which is also a warranty,
b) Declaration of Conformity - on request
c) User's Manual
d) Copies of certificates - on request,
e) calibration certificate - on request
Items: b, c, d can be found at: www.aplisens.pl
5.
APC-2000ALW for MID applications. Technical parameters.
Transmitter supply (Usup) 13.5* ÷ 28V DC
Output signal 4÷20mA + Hart
Ambient temperature -25 ÷ 55
0
C
Relative humidity 10 ÷ 98% with condensation
Case protection ingress (according to EN 60529) IP 66
*
) Backlight setting
of indicate increases the minimum supply voltage by 3V. Display backlight is switched on by
the manufacturer at the order of the customer. In standard transmitters the backlight is turned off.
For the needs of clearing, in accordance with Directive 2004/22/EC, should be used one of the two
metrological checked transmitter output signals: digital HART signal or loop current signal.
Ingress case protection for gaseous fuels 1 and 2 family in accordance with EN 437 provides a design
of transmitter case and cable glands and plugs with seals of the HNBR, or TPE. In the situation of its
own cable glands and plugs you should use components dedicated to Exi zones, to ensure:
temperature, resistance to fuel gas families 1 and 2 and the above degree of protection. Can be used
cable glands with sealants such as TPE's for example: EX1100.20.110 AGRO.
Products in this embodiment meets the following requirements; criteria by EN 12405-1 + A2: 2010
5.1.1. Electromagnetic Compatibility , immunity
Electrostatic Discharge (ESD):
EN 61000-4-2
level 4,
Contact: ±8kV
Air: ±15kV
Criterion A,
Conducted Radio Frequency:
EN 61000-4-6
level 3
0,15… 80MHz - 10V
Criterion A,
Radiated Electromagnetic Field:
EN 61000-4-3
level 3
80 … 1 000MHz – 10V/m
1 … 2,700GHz – 1V/m
Criterion A,
Magnetic Field
EN 61 000-4-8
Level 4
Electrical Fast Transient (Burst):
EN 61000-4-4
± 2kV, I/O
Electrical Slow Transient (Surges)
EN 61000-4-4
Level 3
5.1.2 Short drops in electrical supply
EN 12405-1 + A2:2010
5.1.3. Climatic Immunity
The transmitters can be installed in different climatic
conditions (see p.7) in environments of varying
humidity, also in areas of water vapor condensation
Environment temperature:
EN 60068-2-1, EN 60068-2-2, EN60068-3-1
hot: T = 55
0
C, R
H
= max 55%
cold: T = -25
0
C,
Humid Permanent Heat:
EN60068-2-78
T=55
0
C, R
H
=93%, 96h
Damp Heat Cycle:
EN 60068-2-30
(T = 22 ÷ 55
0
C, R
H
= 80 ÷ 100%, 24h)x2
5.1.4. Mechanical Immunity
Shocks:
EN 60068-2-31, level 2
Vibrations in a wide band:
EN 60068-2-64, test Fh, level 2
