Aplisens APC-2000ALW - Fig. 5. M-Type Connector with M20 X1.5 Thread; Fig. 6. P-Type Connector with M20 X1.5 Thread; Type Connector with Flush Diaphragm with Thread

A1 49 DTR.APC.APR.ALW.03 (ENG)
15
∅35
∅35,1
M30x2
+0,1
1,25
2
diaphragm seal
∅12
∅25
M20x1.5
∅6
25
M20x1,5
∅4
5
∅50
M30x2
∅35,1
16
2
∅25,3
3
0
°
1,25
M20x1.5
2
min.15
M20x1,5
19
1,25
∅6,5
3
∅25,1
min.15
+0,1
15
diaphragm seal
2
2
M30x2
The ring in Fig. 7c have to be welded in place with the word TOP upwards
Fig. 5. M-type connector with M20x1.5 thread
Fig. 6. P-type connector with M20x1.5 thread
Fig. 7. CM30x2-type connector with flush diaphragm with M30x2 thread
i
TOP
Fig.5a. M-type connector
with M20x1.5 thread
Fig.5b. Socket for M-type connector
Fig.6a. P-type connector
with M20x1.5 thread
Fig.6b. Socket for P-type connector
Fig.7a. CM30x2-type connector
with flush diaphragm
with M30x2 thread,
Fig.7b. Socket for
CM30x2-type
connector.
Fig.7c. Socket for
CM30x2-type connector
Sealing: teflon
Order code Socket CM30x2
