Aplisens APC-2000ALW - Fig. 9. Apr-2000 Alw Differential Pressure Transmitter with Ctype Vented Covers; Fig. 10. APR-2000 ALW Differential Pressure Transmitter with a Single Direct Diaphragm Seal (Example)

A1 51 DTR.APC.APR.ALW.03 (ENG)
91,5
4 x M10
80
60
1/4NPT
70
HL
54
41.3
FIELD TERMINALS
18 132 18
133
2 x M6
M20x1,5 Cable gland
Cable
∅5...∅10
153
The electrical
terminals side
The electronic
circuits
and display side
rotation
Lock preventing
of the casing
Earthing terminal
PD electrical connector, IP65
DIN 43650 connector with PG-11
Cable
∅6...∅9
Fig. 9. APR-2000ALW differential pressure transmitter with C type vented covers.
1/4NPT
Sepataror kołnierzowy
Sepataror kołnierzowy
tubusowy typ S-T
płaski typ S-P
Fig. 10. APR-2000ALW differential pressure transmitter with a single direct diaphragm seal (example).
S-T type
tube flanged
diaphragm seal
S-P type
flush flanged
diaphragm seal
