A1 21 DTR.APC.APR.ALW.03
(ENG)
R1/2-type connector with R1/2 tread, available for PED version
CG1/2-type connector with G1/2 tread and flush diaphragm, available for PED version
other connection types by arrangement.
5.3. APR-2000ALW, APR-2200ALW Measurement ranges and metrological
parameters.
5.3.1. APR-2000ALW, Measurement ranges
N
°
Nominal measuring range
(FSO)
Minimum set range
Rangeability
Overpressure
limit
Static pressure
limit
1 0…70bar (0…7MPa) 7bar (700kPa) 10:1
250, 320bar
(40bar for P-type connector)
(250bar for version compliant
with the PED pressure
directive)
2 0...16bar (0...1,6MPa) 1,6bar (160kPa) 10:1
3 0...2,5bar (0...250kPa) 0,25bar (25kPa) 10:1
4 0...1bar (0...100kPa) 70mbar (7kPa) 14:1
5 0...0,25bar (0...25kPa) 10mbar (1kPa) 25:1
6 -0,5…0,5bar (-50…50kPa) 0,1bar (10kPa) 10:1
7 -100...100mbar (-10...10kPa) 4mbar (0,4kPa) 50:1
8 -5...70mbar (-0,5...7kPa) 4mbar (0,4kPa) 18:1
9 -20...20mbar (-2...2kPa) 2mbar (0,2kPa) 20:1
20 bar
5.3.2. APR-2200ALW, Measurement ranges
Nominal range
(FSO)
Minimum set
range
Vertical spacing
of diaphragm
seals.
Maximum configurable range dependent
on the actual vertical spacing of
diaphragm seals. (m
)
Static
pressure
limit
-160...160 mbar 0,1 mH2O
≤ 1,7m
[1,6+( vertical spacing of sealsx94)]mH
2
O
40bar
-1,6...16 bar
1bar
≤ 15m
16bar
40bar
The maximum vertical diaphragm seal spacing shown in the table applies to level measurement,
ensuring that it is possible to set the zero point of the transmitter when the tank is empty.
For measurements of density or phase boundaries (in the sugar and chemical industries and in
refineries) the vertical spacing of the diaphragm seals can be larger.
5.3.3. APR-2000ALW, APR-2200ALW Metrological
parameters
Accuracy ± 0,075% (FSO) for the APR-2000ALW nominal range
Long term stability
≤
accuracy / 3 years
Error due to supply voltage changes ± 0,002%(FSO)/1V
Thermal error ± 0,08%(FSO)/10ºC
Thermal error for the whole thermal
compensation range ± 0,3%(FSO)
Zero shift error for static pressure* ± 0,08 % (FSO)/10bar
± 0,01 % (FSO)/10bar (for range n°4)
± 0,03 % (FSO)/10bar (for range n°5, 6)
Cut-off on radical characteristic curve up to10% of flow.
*) zeroing in static pressure conditions with zero differential pressure eliminate this error.
APR... transmitters, in the PED Pressure Directive versions, are produced with a measurement range in the
interval from –100 kPa to 2,5MPa, with the static pressure 25MPa and the overpressure up to 27,5 MPa.
The permissible operating temperature for option according to H1D+H1 Module is between -25°C and 100°C.
The permissible operating temperature for option according to B+D Module is between -25ºC and 70ºC.
APR transmitters... which conform to PED are characterised by a measurement range of between -100kPa and
2.5MPa, static pressure of 25MPa and the overpressure of 27.5MPa.
5.3.4. APR-2000ALW, Pressure Connectors
APR-2000/ALW– C-type connector to mount together with a valve manifold see fig.9, available for PED version
APR-2000/ALW with single direct diaphragm seal – as in the example (fig.10) or with other diaphragm seals in
accordance with “DIAPHRAGM SEALS” catalogue cards.
5.3.5. APR-2200ALW. Pressure Connectors - diaphragm seals – see “DIAPHRAGM
SEALS ”catalogue cards.
