Aplisens APC-2000ALW - Fig. 17. APR-2000 GALW Smart Differential Pressure Transmitter for Low Ranges

A1 56 DTR.APC.APR.ALW.03 (ENG)
Valve manifold
54
28
4
x
∅12
∅14
∅6
∅
9
34
Adapter M20x1.5/ x1
61
1/4 NPT
L
34
H
∅51
Fig. a. Fig. b.
188
∅51
FIELD TERMINALS
18 132 18
Fig. c.
SW27
∅51
194
∅12
M20
M8x10
2holes
(G1/2")
15
25,5
terminals side
The electrical The electronic
circuits
and display side
steel impulse lines
Adapter for
valve manifold or
line connector
Weidable impulse
Fig. 17. APR-2000GALW smart differential pressure transmitter for low ranges.
a). APR-2000GALW transmitter – industrial version with C type process connector to
mount together with a valve manifold or weldable impulse line connectors.
b). APR-2000GALW transmitter – economical version with PCV type process connector.
c). APR-2000GALW transmitter – with GP or P type process connector (G1/2” or
M20x1,5 thread).
