Aplisens APC-2000ALW User Manual

A1 20 DTR.APC.APR.ALW.03 (ENG)
5.2. APC-2000ALW Measurement ranges and metrological parameters.
5.2.1. APC..., Measurement ranges
N °
Nominal measuring range
(FSO)
Minimum set range Rangeability
Overpressure limit
(without hysteresis)
1.
0...1000bar (0...100MPa) 10bar (1MPa) 100:1 1200bar (120MPa)
2.
0...300bar (0...30MPa) 3bar (300kPa) 100:1
450bar (45MPa)
3.
0...160bar (0...16MPa) 1,6bar (160kPa) 100:1
450bar (45MPa)
4.
0...70bar (0...7MPa) 0,7bar (70kPa) 100:1
140bar (14MPa)
5.
0...25bar (0...2,5MPa) 0,25bar (25kPa) 100:1
50bar (5MPa)
6.
0...7bar (0...0,7MPa) 0,07bar (7kPa) 100:1
14bar (1,4MPa)
7.
-1...6bar (-100...600kPa) 300mbar (30kPa) 23:1
14bar (1,4MPa)
8.
0...2bar (0...200kPa) 100mbar (10kPa) 20:1
4bar (400kPa)
9.
0...1bar (0...100kPa) 50mbar (5kPa) 20:1
2bar (200kPa)
10.
-0,5...0,5bar (-50...50kPa) 50mbar (5kPa) 20:1
2bar (200kPa)
11.
0...0,25bar (0...25kPa) 25mbar (2,5kPa) 10:1
1bar (100kPa)
12.
-100...100mbar (-10...10kPa) 20mbar (2kPa) 10:1
1bar (100kPa)
13.
-15...70mbar* (-15...7kPa) 5mbar (0,5kPa) 17:1
0,5bar (50kPa)
14.
0...1,3bar abs (0...110kPa abs) 50mbar abs (5kPa abs) 26:1
2bar (200kPa)
15.
0...7bar abs (0...7MPa abs) 0,07bar abs (7kPa abs) 100:1
14bar (1,4MPa)
16.
0...25bar abs (0...2,5MPa abs) 0,25bar abs (25kPa abs)
100:1
50bar (5MPa)
17.
0...70bar abs (0...7MPa abs) 0,7bar abs (70kPa abs) 100:1
140bar (14MPa)
* - only for transmitters without diaphragm seal,
5.2.2. APC..., Metrological parameters
Accuracy max ± 0,075% for the basic range (0,16% for range 14)
Long term stability ≤ accuracy for 3 years (for the nominal measuring range)
Error due to supply voltage changes max ± 0,002%(FSO)/1V
Thermal error max ± 0,08%(FSO)/10ºC
max ± 0,1% FSO/10°C for n°12, 13, 14 ranges.
Thermal error for the whole thermal max ± 0,25%(FSO)
compensation range (max ± 0,4% FSO/10°C for n°12, 13, 14 ranges.
5.2.3. APC…, APR… Metrological Parameters according to PED version.
APC... transmitters, in the PED Pressure Directive versions, are produced with a measurement range in the
interval from –100 kPa to 40MPa gage, or from 0 to 40MPa absolute, with the overpressure up to 44 MPa.
Temperature limits -40 ÷ 100
0
C (-40 ÷ 150
0
C with S-Mazut connector) for options according to H1D+H1
Modules. Temperature limits -25 ÷ 70
0
C for options according to B+D Modules.
APC… pressure transmitters with the S-Mazut seal pressure connection, assembled with the PED version can
be produced within the range–100 kPa to 10 MPa gage, or within the 0- 10 MPa absolute, and the overpressure
up to 11 MPa.
APR... transmitters, in the PED Pressure Directive versions, are produced with a measurement range in the
interval from –100 kPa to 2,5MPa, with the static pressure 25MPa and the overpressure up to 27,5 MPa.
Temperature limit for option according to H1D+H1 Module is -25÷100ºC and for option according to B+D Module
is -25÷70ºC.
5.2.3. APC..., Pressure Connectors
M-type connector with M20x1.5 thread – see figure 5a, available for PED version
P-type connector with M20x1.5 thread – see figure 6a, available for PED version
CM30x2-type connector with flush diaphragm – see figure 7a,
G1/2 -type connector with G1/2” thread – see figure 8a, available for PED version
GP -type connector with G1/2” thread, available for PED version
CG1-type connector with G1” thread and flush diaphragm – see figure 8e, available for PED version
RM-type connector with M20x1.5 thread and radiator
RP-type connector with M20x1.5 thread and radiator
G1/4-type connector with G1/4 thread, available for PED version
1/2"NPT -type connector with 1/2"NPT tread, available for PED version
