Applent Instruments AT528 - AT528 L AC Resistance Range

27
Specification
2
50V
50.000V
0.002V
0.5%±4
0.5%±3
0.1%±5
7.1.3 AT528L AC Resistance Range
RANGE
Max
Reading
Resolution FAST MED SLOW
Test
Current
1
200mΩ
220.0mΩ
0.1mΩ
0.8%±4
0.6%±3
0.5%±2
1mA
2
2Ω
2.200Ω
1mΩ
0.8%±4
0.6%±3
0.5%±2
0.1mA
3
20Ω
22.00Ω
10mΩ
0.8%±4
0.6%±3
0.5%±2
10μA
4
200Ω
220.0Ω
100mΩ
0.8%±4
0.6%±3
0.5%±2
5μA
Open-circuit Voltage: <30 mVrms
7.1.4 AT528L DC Voltage Range
RANGE
Max
Reading
Resolution FAST MED SLOW
1
5V
5.000V
1mV
0.5%±5
0.5%±3
0.5%±2
2
50V
50.00V
10mV
0.5%±5
0.5%±3
0.5%±2
7.2 Features
 3.5inch 16M color TFT-LCD screen
 Internal, External and Manual trigger.
 Range Auto, Manual and Nominal mode
 ABS, PER and SEQ sorting methods
 Short-circuit clear zero for all ranges
 Temperature compensation
 Data hold function
 Customizable beep feature
 Keypad lock
 Switch both in Chinese and English
 Auto power off
 Four-terminal test method
 Built-in Mini-USB to RS232 interface
 SCPI commands available.
 8.4V Li, 2200mAh rechargeable battery
 Charging time＜5h
 Working time≥8h @25% Brightness
 Power: <5W
 Dimension: 210.76mm*130.23mm*37.88mm
 Weight: 500g
