Applied Biosystems GeneAmp PCR System 9700 User Guide

DRAFT
October 24, 2007 9:40 am, 44343363 D 03 Overview.fm
Chapter 1 Dual 96 Sample Block Module Overview
1-10 GeneAmp PCR System 9700 Dual 96 Sample Block Module User Guide
Placing the
Sample Tray or
Plate onto
the Block
To place a sample tray or plate onto the block:
1. Lift the sample tray from the 96-well base and place it in the sample block.
Place the MicroAmp tray or plate so that well H12 is located at the upper right
corner of the tray.
IMPORTANT! Do not place the base into the sample block.
2. Slide the heated cover forward.
Note: Ensure that the cover is pulled completely forward for a proper seal.
3. Pull the heated cover lever down to engage the heated cover with the reaction
plate.
4. Process the samples
IMPORTANT! Do not open the cover when the block temperature is above 27 °C
because sample caps may pop off or jam.
A B C D E F G H
1234567891011
12
GR1070
H12
Figure 1-4 Align well H12 with upper right corner of the tray
