Applied Precision RS 2130 User Manual

Reference Standard RS 2x30, RS 1x30
User’s Guide
RS-UG91-EN www.appliedp.com
18
3.2.21 OPS Measurement Mode Menu
OPS Meas/Test -> - start of OPS Measurement Mode screen
Fout0 Config … - Impulse Output Fout0 Menu (this functionality is dependent on Fout0 settings)
MUT Constant - parameter setting the constant of Meter Under Test
Sample Type - parameter setting the mode of operation of OPS Measurement Mode.
Parameter value is ‘Impulses’ or ‘Int. Time’.
Int. Time - parameter setting the Integration Time for OPS Measurement Mode
No. of Impulses - parameter setting the Number of Impulses for OPS Measurement Mode
No. of Samples - parameter setting the Number of Samples for OPS Measurement Mode
3.2.22 Dosage Menu
Start - dosage instant start
Stop - dosage instant stop
Mode - setting of dosage function in respect of a type – TIME, ACTIVE ENERGY,
REACTIVE ENERGY or APPARENT ENERGY, SQUARE VOLTAGE, SQUARE
CURRENT, OFF,
Time - setting the dosage lasting for time dosage, stated in seconds,
Energy - setting the dosage amount for energy type dosage,
Energy Unit - setting the unit of energy when energy dosage is set,
Contact SI Mode - setting the SI contact into the state CONTACT OPEN or CONTACT CLOSED
or AUTO,
Contact SU Mode - setting the SU contact into the state CONTACT OPEN or CONTACT CLOSED
or AUTO,
Contact SI Auto ... - entry to Contact SI Auto Mode Menu,
Contact SU Auto ... - entry to Contact SU Auto Mode Menu,
Contact SI State - setting the SI contact state – open or closed,
Contact SU State - setting the SU contact state – open or closed,
3.2.23 SI/SU Contacts Menu in Auto Mode
Start State - setting the SI/SU contact state for dosage start, there are three options –OPEN,
CLOSED and UNCHANGED,
Start Delay - setting the delay of dosage starting, stated in seconds
Stop State - setting the SI/SU contact state for dosage stop, there are three options – OPEN,
CLOSED and UNCHANGED,
Stop Delay - setting the delay of dosage stopping, stated in seconds
3.2.24 Control Port Menu
Signal OUTx - parameter of the direct control of the appropriate bite at the user control port
(value LOW corresponds to the logical 0, and value HIGH to logical 1,
respectively),
Signal Inx - parameter (which can be changed) setting the actual state of appropriate bites
at the user control port (value LOW corresponds to the logical 0, and value HIGH
to logical 1, respectively),
Init values... - control port initializing menu,
