Applied Precision RS 2130 User Manual

Reference Standard RS 2x30, RS 1x30
User’s Guide
www.appliedp.com RS-UG91-EN
45
5.17.5 Quantities list
Q #
QUANTITY
codeLF
codeSF
SI unit
Q01
Active Power
POW:AC
P
W
Q02
Voltage
VOLT:AC
U
V
Q03
Current
CURR:AC
I
A
Q04
Reactive Power
POW:AC:REAC
Q
VA
Q05
Apparent Power
POW:AC:APP
S
VA
Q06
Power Factor
POW:AC:FACT
pf
-
Q07
Impedance Module
IMP:AC:MOD
Z
ohm
Q08
Impedance Phase
IMP:AC:PHAS
Ph
deg
Q09
Impedance Real Part
IMP:AC:REAL
R
ohm
Q10
Impedance Imaginar Part
IMP:AC:IMAG
X
ohm
Q11
Frequency
FREQ
F
Hz
Q12
Distortion of Voltage
VOLT:AC:DIST
dU
%
Q13
Distortion of Current
CURR:AC:DIST
dI
%
Q14
Phase UU
PHAS:UU
phU
deg
Q15
Phase UI in Lx channel
PHAS:UI
phI
deg
Q16
Phase-to-phase Voltage
VOLT:AC:PP
Upp
V
Q17
Sum of Active Power
POW:AC:SUM
sP
W
Q18
Sum of Reactive Power
POW:AC:SUM:REAC
sS
VA
Q19
Sum of Apparent Power
POW:AC:SUM:APP
sQ
VA
Q20
Sum of square Voltage / 1
VOLT:AC:SUM:SQR
sUU
W
Q21
Sum of square Current / 1
CURR:AC:SUM:SQR
sII
W
