Applied Precision RS 2130 User Manual

Reference Standard RS 2x30, RS 1x30
User’s Guide
RS-UG91-EN www.appliedp.com
42
- 4 or F4 ............... key for selecting channel (1=L1, 2=L2, 3=L3) for which statistical values are
shown. Channel can be changed also during running logging and don’t require
recalculation for getting actual statistical values. Some quantities (frequency)
are not measured as three-phase quantities therefore channel is not shown for
them.
- 5 or F5 ............... key for entering “HISTORY VALUES” window in which all measured values are
available.
HISTORY VALUES Window
Description of window items:
1
st
Line:
- window ............. name of the window: “HISTORY VALUES”
- quantity ............ name of the quantity for which values are shown. Names of all quantities:
"Active Power [W]", "Voltage [V] ", "Current [A]", "Reactive Power[VAr]",
"Apparent Power [VA]", "Phase U [°]", "Phase I [°]", "Distortion U [%]",
"Distortion I [%]", "Frequency [Hz]"
2
nd
- 7
th
Line:
- DATA ................ measured data with its number (counted from 1), value and date and time.
Empty 7
th
line indicates reaching end of list during browsing or paging data.
8
th
Line – keys:
- ▲ and ▼ .............. keys for browsing data by one line
- ◄ and ► .............. keys for paging data by 6 lines
- 3 or F3 ............... key for selecting quantity for which measured values are shown.
- 4 or F4 ............... key for selecting channel (1=L1, 2=L2, 3=L3) for which measured values are
shown. Selected channel is shown in last line between <4> and <5> keys.
- 5 or F5 ............... key for exiting “HISTORY VALUES” window and return into “HISTORY
STATISTIC” window
- Backspace ....... key for jumping to the beginning of the list of data
- DEL or INS ........ key for jumping to the end of the list of data
Remarks / known issues:
• Selection of quantities is not available (all measured quantities are always logged)
• Integration time cannot be changed and is always same as Time Base value
• Obtaining of historical values using command SYST:HIST:GET? maybe not fully functional in fw 7.00 for all
quantities
HISTORY VALUES of Active Power [W]
1: +1.21234E+02 /2009-12-21 09:17:20
2: +1.21216E+02 /2009-12-21 09:17:21
3: +1.21209E+02 /2009-12-21 09:17:22
4: +1.21195E+02 /2009-12-21 09:17:23
5: +1.21176E+02 /2009-12-21 09:17:24
6: +1.21157E+02 /2009-12-21 09:17:25
<▲,▼> <◄,►> <3>Quant <4>Chnl=x <5>Exit
