APRILIA MX 50 - Lighting System Maintenance; Replacing Parking Light Bulb

65
PARKING LIGHT BULB
To extract the bulb socket, do not pull its
electric wires.
◆ Grasp the bulb socket (6), pull and disconnect it
from its seat.
◆ Withdraw the parking light bulb (1) and replace it
with one of the same type.
CHANGING THE DASHBOARD BULBS
Before changing a bulb, check the fuses,
see CHANGING THE FUSES.
The dashboard contains:
◆ The warning light bulbs.
◆ The dashboard lighting bulb.

Fig. 65
Fig. 66
1
2
9
8
7
6
