APsystems YC500A/I Microinverter Datasheet
Input Data (DC )
Recommended PV Module Power (STC)Range
180W-310W
MPPT Voltage Range
22V-45V
Operation Voltage Range
16V-52V
Maximum Input Voltage
55V
Startup Voltage
22V
Maximum Input Current
12A x 2
Output Data (AC)
Nominal Out put Voltage
208V
1
240V
1
Maximum Continuous Output Power
500W
500W
Nominal Output Current
2.4A
2.08A
Default Output Voltage R ange
183V-229V
2
211V-264V
2
Maximum Output Fault Current (peak)
33.4A
54.8A
Maximum Output Fault Current (RMS )
2.79A
4.85A
Maximum Output Fault Current Duration
1.875ms
1.639ms
Reactive Current
0.1A
Extended Output Voltage Range
181V-298V
Nominal Out put Frequency
60Hz
Default Output Frequency Range
59.3Hz-60.5Hz
2
Extended Output Frequency Range
55.1Hz -64.9Hz
Power Factor
>0.99
Total Harmonic Distortion
<3%
Maximum Units per Branch
6 for 20 B reaker
3
7 for20A Brea ker
3
Efficiency
Peak Efficie ncy
95.5%
CEC Weighted Efficiency
95%
Nominal MPPT Efficiency
99.5%
Night Po wer Consumption
120mW
Mechanical Data
Operating Ambie nt Temperature Range
-40
o
F to +149
o
F (-40°C to +65°C )
Operating Internal Temperature Range
-40
o
F to +185
o
F (-40°C to +85°C )
Storage Temperature Range
-40
o
F to +185
o
F (-40°C to +85°C )
Dimensions (W x H x D)
221mm X 167mm X 29mm
(8.7” X 6.6” X 1.1”)
Weight
5.5lbs/2.5kg
AC BUS
12AWG
Enclosure Rating
NEMA 6
Cooling
Natural Convection
