APsystems YC500-A - Sample Wiring Diagrams; Sample wiring diagram - 120 V;240 V split phase

APsystems YC500-A Installation/User Manual 21
Figure 11
Sample Wiring Diagrams
Sample Wiring Diagram - 120V/240V Split Phase
APsystems YC500A/I Installation/User Manual
21
Wiring Diagram
Sample Wiring Diagram - 120V/ 240V Split Phase
AC JUNCTION BOX
ENERGY COMMUNICATION UNIT
ETHERNET CONNECTI ON
TO BROADBAND ROUTER
120 VAC POWER CABLE
AC BRANCH END CABLE
RED - L1
BLACK - L2
WHITE - N
METER
BRANCH END CAP
INSTALLED ON THE OPEN AC CONNECTOR
UP TO 7 YC500 PER
BRANCH CIRCUIT
Apsystems
YC500-NA
20 AMP CIRCUIT
BREAKER PER
BRANCH CIRCUIT
TO METER
OR AC
DISTRIB UTION
PANEL
NEUTRAL
GROUND
DISTRIBUTION PANEL
120V/240V SPLIT PHASE
SOLAR
PANEL
ECU
Figure 14
