PV voltage/ PV current/ PV power
(PV1 and PV2 switch every 5
seconds)
PV2 voltage=300V, PV2 current=2.0A, PV2 power=600W
Battery voltage, charging stage/
Configured battery parameters/
Charging or discharging current
Battery voltage=50.4V, Bulk charging voltage=56.4V,
Charging current=20A
Battery voltage=53.9V, Floating charging voltage=54.0V,
Charging current=1A
Battery voltage=50.4V, Low DC cut-off voltage=44.0V,
Discharging current=48A
