LCD Display
The LCD display information will be switched in turn by pressing the “ ” or “ ” button. The selectable
information is switched as the following table in order.
Utility voltage/ Utility frequency,
Utility current switch every 5
second
Input Voltage=230V, Input frequency=50Hz
Input Voltage=230V, Input current=4.8A
If solar energy feed to grid:
Input Voltage=230V, Feed current=8.8A
PV voltage/ PV current/ PV power
(PV1 and PV2 switch every 5
seconds)
PV1 voltage=300V, PV1 current=2.0A, PV1 power=600W
