57
Three inverters in one phase, two inverters in second phase and one inverter for the third phase:
Power Connection
Communication Connection
2
1
3
4
5
6
P1
P3
P2
Three inverters in one phase and only one inverter for the remaining two phases:
Power Connection
Communication Connection
2
1
3
4
5
P1
P3P2
