20
Overview
No. Designation
1 Counter plate
2 Seed drill
3 Soil tillage implement
Procedure
To attach the seed drill on a soil tillage implement:
Step Description
1 Fasten the counter plate (1) on the soil tillage implement (3).
The counter plate must be parallel to the ground.
2 Use the lifting gear to place the seeder (2) on the counter plate (1).
3 Fasten the seeder (2) with bolts and nuts on the counter plate (3).
4.2 Attaching the seed drill to a tractor
Purpose
For operation on the field, the seed drill can be attached directly to a tractor.
Requirements
The following requirement must be fulfilled for this work step:
• The implement is disconnected from the power source, see Disconnecting the
seed drill from the power source On page 40.
