9
No. Designation Function
1 Fan sensor (pressure
monitor)
•
Preventing the seeding shaft from being
switched on as long as the fan is not switched
on.
•
Preventing blockage of the seed drill due to un-
intentional or early switching on of the seeding
shaft.
2 Pressure switch
•
Reporting to the control box if the pressure is
too high (> 10 bar) in the tank line.
3 Hydraulic block
•
Limiting the oil quantity to the hydraulic motor.
4 Hydraulic motor
•
Driving the fan.
5 Temperature measuring
strips
•
Displaying the temperature of the hydraulic mo-
tor.
Functioning of the sensors
The fan sensor monitors the air pressure on the pressure side of the fan.
The pressure switch monitors the pressure in the tank line of the hydraulic motor.
As soon as one of the sensors reports an error, the message "Fan error" appears on
the control box.
Functioning of the temperature measuring strip
The segments of the temperature measuring strip turn black when the respective tem-
perature range has been reached or exceeded.
Temperatures above 80° C cause destruction of the gaskets in the hydraulic motor.
2.3 Scope of delivery
The scope of delivery includes all assembly groups and components that are deliv-
ered as a standard by APV - Technische Produkte GmbH.
Pos.
Rate Designation
1 1 Basic implement
1.1 1 Steel frame
1.2 1 Seed tank
1.3 1 Extra seeding shaft (standard accessory)
2 1 Counter plate
3 8 Dispersion plate along with fastening material
4 4 Hexagonal bar
5 1 Hose roll (25 m)
6 1 Calibration bag
7 1 Calibration scale
8 1 Hexagon key (fastened on the steel frame)
