APV PS 120 M1 User Manual

48
No. Description Colour Cross-section
(mm²)
1 Implement cable (pin 1) Blue 4.0
2 Implement cable (pin 2) brown 4.0
3 Implement cable (pin 3) Blue 1.5
4 Implement cable (pin 4) Grey 1.5
5 Implement cable (pin 5) brown 1.5
6 Implement cable (pin 6) Black 1.5
7 Seeding shaft motor Black 1.5
8 Seeding shaft motor red 1.5
9 Calibration button (optional) brown 0.75
10 Calibration button (optional) Black 0.75
11 Fan (not with HF) Blue 4.0
12 Fan (not with HF) brown 4.0
13 Fill level sensor (optional) brown 0.75
14 Fill level sensor (optional) Blue 0.75
15 Fill level sensor (optional) white 0.75
16 Fan speed sensor (optional HF) brown 0.75
17 Fan speed sensor (optional HF) Blue 0.75
18 Fan speed sensor (optional HF) Black 0.75
19 Pressure switch (only HF) Blue 1.5
20 Pressure switch (only HF) brown 1.5
21 Hydraulic switch (only HF) Black 1.5
22 Hydraulic switch (only HF) brown 1.5
