Aquatec orca - Setup and Delivery; Setup Safety Information

Aquatec®ORCA/ORCAF/ORCAXL
3Setup
3.1Safetyinformation
IMPORTANT!
–Checkthepartsfortransportdamagebefore
commissioningandcontactthedealerifrequired.
–Ensureduringassemblythatthepartsarepositioned
correctlywithrespecttooneanother.
3.2Scopeofdelivery
ThisusermanualreferstothemodelsORCA,ORCAFandORCA
XL.TheseModelsdifferinweightandthemaximumuserweight,see
section9.1Dimensionsandweight,page22
.Aseat-andbackrest
coverisoptionallyavailableforallthreemodels.Thebackrestcan
notbeloweredonmodelORCAF.
Thefollowingcomponentsareincludedwithinthescopeofdelivery:
Seat
A
Sideflap
B
Seatplate
C
Hingeforbackrest
D
Liftingscissors
E
Spindlefootretainer
F
Rearsuctioncups(twotabswiththread)
G
Baseplate
H
Guidefortheslidingshoe
I
Slidingshoe
J
Frontsuctioncups(onetabwithhead)
