Aquatec®ORCA/ORCAF/ORCAXL
5Transport
5.1Safetyinformation
CAUTION!
Thebackrestisnotlockedontheseatwhenitisfolded
togetherandcancomeapart.
–Donotremovethesuctioncupswhentransporting
thebathlift.
–Removethehandcontrolfromthebackrestfor
transport.
–Refertothestorageandshippingconditionsinsection
9.4EnvironmentalParameters,page23
.
1.Removethehandcontrol.
2.Disassemblethebathliftintotwosectionsfortransport(seat
andbackrest),→5.2Removingthebathlift,page16
.
5.2Removingthebathlift
1.Letthewateroutofthebathtub.
2.LowerthebathliftusingtheDownbuttonuntilthebackrest
stopsintheloweredendposition,→4.2Controllingthebath
lift,page13
.
3.Unlockthejacksocketonthespiralcableofthehandcontrolby
pushinguptheunlockingsleeveandpullitoffthejackplug.
IMPORTANT!
Riskofdamage
–Whenfoldingthebackrestdown,ensurethat
spiralcableofthehandcontroldoesnotbecome
trapped.
–Donotfoldthebackrestdownifthereiswater
inthebathtub.
4.Holdthebackrestattheheadendwithonehandandfoldit
forwardstotheendposition.
5.Pullthebackrestupofftheseatandoutofthebathtub.
