ARB RD151 - Installing the Air Locker; Installing the Carrier Bearings

3 Installing the Air Locker
8
3.1 Installing the Carrier Bearings
 Apply a thin film of high pressure grease to both bearing journals of
the Air Locker.
 Using a bearing press or arbor press, press one of the supplied
tapered roller bearing cones onto the bearing journal opposite to
the ring gear flange of the differential carrier (As shown in Figure 2.)
until the bearing seats firmly against the bearing journal shoulder.
Figure
2.
 Invert the Air Locker and press the second supplied bearing cone
onto the bearing journal on the ring gear flange side of the
differential (the seal housing side) until the bearing seats firmly
against the bearing journal shoulder.
