ARB RD151 - Itemized Parts List

7 Parts List
42
7.3 Itemized Parts List
(see exploded diagram Fig. 26.)
ITEM #
QTY
DESCRIPTION
PART #
NOTES
1
1
FLANGE CAP KIT
027341SP
2
1
BONDED SEAL
160703SP
3
1
CLUTCH GEAR & WAVESPRING KIT
050904SP
4
1
WAVESPRING
150704SP
5
1
LONG CROSS SHAFT
060204SP
6
1
SPIDER BLOCK
070201SP
7
1
SIDE GEAR
SEE NOTE
3
8
1
RETAINING PIN SET (PK OF 4)
120601SP
9
2
BEARING RETAINING SLEEVE
190104
10
1
3mm MASTER SHIM
150356
11
1
MASTER SHIM
150305
12
1
SHIM KIT
SHK009
13
1
SEAL HOUSING KIT
081805SP
14
1
SEAL HOUSING O-RINGS (PK OF 2)
160207-2
1
15
2
TAPERED ROLLER BEARING
160119
2
16
2
ANTI-FRICTION BUSHING (PTFE)
160805SP
17
1
SPLINED SIDE GEAR
SEE NOTE
3
18
4
PINION THRUST WASHER
SEE NOTE
4
19
4
PINION GEAR
SEE NOTE
3
20
2
SHORT CROSS SHAFT
060403SP
21
2
SIDE GEAR THRUST WASHER
SEE NOTE
4
22
1
DIFFERENTIAL CASE
013041SP
23
1
COUNTERSUNK SCREW
200213SP
*
1
BULKHEAD FITTING KIT (BANJO TYPE)
170114
5
*
1
AIR LINE (6mm DIA X 6m LONG)
170314SP
5
*
1
SOLENOID VALVE (12V)
180103
*
1
SWITCH|FR LOCKER
180223
*
1
CABLE TIE (PK OF 25)
180305
*
1
OPERATION & SERVICE MANUAL
210200
*
1
INSTALLATION GUIDE
2102151
*
Not illustrated in exploded view
NOTES
1
For replacement O-rings use only BS136 Viton 75.
2
For replacement bearings use ARB #160119 (Toyota Aust #90366T0031)
3
Available only as complete 6 gear set #728H191
Spare axle retaining clips may be required (not supplied) to refit CV shafts.
Spare axle shaft oil seal may be required (not supplied – Toyota Aust #9031147012)
For 8” IFS with 50mm carrier bearings refer to RD131 (Section 2.131).
For 8” IFS with 53mm carrier bearings and cast iron housing, refer to
RD111 (Section 2.111) or RD121 (Section 2.121).
4
Available only as complete thrust washer kit #730H01
5
All diffs produced before serial #17070001 came with 5mm air connection system.
For information contact ARB.
Part No. 2102151
Revision 27/10/2020
Copyright © 2015 by ARB Corporation Limited
