Arcam AVR400 Handbook

E-52
trouble-
shooting
Problem Check that...
ere are no lights on the unit
<
the power cord is plugged into the AVR400 and the mains socket it is
plugged into is switched on.
<
the power button is pressed in.
If a red LED is present, the AVR400 is in standby mode. Press any button on the
front panel or remote control.
e unit responds erratically
or not at all to the remote
control
<
there are fresh batteries in the remote control.
<
the front panel window is visible and you are pointing the remote control
towards it.
e front panel display is
blank
<
the display hasn’t been turned o. Press the DISPLAY button on the front
panel or remote control.
No picture is being produced
<
your viewing device is turned on and switched to display your AVR400. Test
by pressing the MENU button on the AVR400 or on the remote and look for
the main menu screen on your display device.
<
the correct video input is selected on the AVR400.
<
the “Video Source” has been set correctly in the “Input Cong.” menu
<
the video source is on, is operating normally, and is in ‘play’ mode if
appropriate.
<
you have the AVR400 in a video resolution that is compatible with the
connection you are using and with your display device. For example,
composite video is only capable of carrying 480i and 576i resolutions. Test
this by pressing and holding the OK key for more than two seconds to force
480i / 576i output resolutions.
ere are bright edges or
‘ghosts’ on the picture
<
the cables used for analogue video connections are designed to carry video
(i.e., they are 75 coaxial cables).
<
ensure the ‘sharpness’ control on your display device is switched o or set to
near minimum.
<
for HDMI connections, try using a shorter cable or alternatively a dierent
brand.
No sound is produced
<
the correct input has been selected.
<
the “Audio Source” has been set correctly in the “Input Cong.” menu
<
the source equipment is on, is operating normally and is in ‘play’ mode if
appropriate.
<
the volume is turned up to a reasonable level and the AVR400 is not in mute
mode.
e sound is poor or distorted
<
you have not excessively increased the input sensitivity (i.e. reduced the
maximum input signal voltage) in the Input Cong. menu if an analogue
input is being used.
<
you have selected the correct size of speakers to suit your system in the setup
menu.

Arcam AVR400 Specifications

General

Output level	6000 mV
Receiver type	-
Frequency range	20 - 20000 Hz
Output impedance	50 Ω
Input sensitivity	4000 mV
Pre-out connectivity	Yes
Audio output channels	7.1 channels
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	0.02 %
Power output per channel (20-20KHz@8 Ohm)	- W
HDMI in	5
Composite video in	4
Digital audio optical in	2
Ethernet LAN (RJ-45) ports	1
Multichannel audio input type	RCA
Component video (YPbPr/YCbCr) in	3
Headphone connectivity	3.5 mm
Connectivity technology	Wired
Speakers connectivity type	Binding post
Audio formats supported	AAC, FLAC, MP3, WMA
Wi-Fi	No
Supported radio bands	AM, DAB, FM
HDMI version	1.4a
Product color	Silver
Audio decoders	Dolby Digital, Dolby Digital EX, Dolby Digital Plus, Dolby Pro Logic, Dolby Pro Logic IIx, Dolby TrueHD, DTS, DTS 96/24, DTS Neo:6, DTS-ES, DTS-ES (Discrete 6.1), DTS-ES (Matrix 6.1), DTS-HD Master Audio
Volume control	Rotary
Power consumption (standby)	0.5 W
Power consumption (typical)	100 W
Certification	FCC, CE
Package weight	20000 g
Cables included	AC

Weight and Dimensions

Depth	425 mm
Width	435 mm
Height	172 mm
Weight	15500 g
