3-4
ASSEMBLING/INSTALLING
1. Apply a coat of grease to the housing and reel.
GR119D
GR121D
2. Install the reel assembly with rope wound in the
appropriate direction.
GR507D
GR111D
3. Install the springs and ratchets.
GR506D
GR505D
4. Install the plate and secure it with the screw.
GR503D
! WARNING
Exercise extreme caution when installing as the
spring may disengage and cause severe injury.
To Next Page
