57
14.5.5 Cockpit assembly - routing - mechanical cables
38977 (2X)
1. Reposition the extensions into the
bridge, making sure the surfaces
are free of grease.
2. Route the cables.
3. Set the shifters on the extensions.
4. Rotate the extensions to the
desired angle.
5. Install the extension caps (SKU:
38977, same cap for both sides).
6. Tighten the extension fixing
screws to 4 Nm.
7. Insert the bridge plug
(SKU: 81521).
