19
Exit derailleur cables through bottom bracket (BB) hole.
Insert in the appropriate slots in the BB guide.
Making sure the pipe is aligned with the top hole,
insert BB guide in the square hole until it clicks.
DC
DC = Derailleur Cable (mech.)
DC
KRYPTON PRO 302A 7. Cable and Housing Routing - Mechanical Shifting
