26
KRYPTON PRO 302A 8. Stem Assembly
CARBON FIBER
ASSEMBLY
PASTE
Stem Assembly - Step #5
1. Install the Bar Clamp (7.4) using the 4 M5x14mm Screws (7.11).
Apply grease on the screw threads and only engage all screw
threads.
2. First, tighten the top screws. Torque at 5Nm.
3. Second, tighten the bottom screws. Torque at 5Nm.
4. Pull back the Hood over the top screws and insert the Hood’s
tab into the Bar Clamp groove.
Note: There must be no gap between the Bar Clamp and the Stem
Carbon Body after torquing the Top Screws. The gap will be at the
front (bottom screws).
